Hardware

Combo Smart Kiosk L

This product is currently out of stock and unavailable.

The Most Dependable Kiosk Solution

THE MOST DEPENDABLE KIOSK TURNKEY IDENTITY CAPTURE SOLUTION WITH NO MOVING PARTS
After years of being in service this powerful scanner boasts a high availability accurate and dependable solution you can count on. This is the perfect textbook user experience that supports full-page scanning for automated border control, airline check-in, ATMs and many other industry applications. [cite: 1, 2]

Key Features

  • Simple Software Installation – SDK with API documentation and sample code included. [cite: 3]
  • Multi-Faceted OS Support – Windows and Linux Drivers available for the driver SDK as well as TWAIN support. [cite: 4]
  • Seamless Hardware Integration – Compact, brick-shaped design with a rotatable frame for easy kiosk installation. [cite: 5]
  • Automated Scanning – Detects and scans documents instantly, ensuring fast data extraction and fraud detection. [cite: 6]
  • Adaptable to Light Conditions – Built-in adaptive lighting ensures reliable performance in varying environments. [cite: 7]
  • Durable and Reliable – Designed with no moving parts or consumables, backed by a 3-year warranty. [cite: 8]



Specifications

(Ideal for automated border control, airline check-in, and ATMs. Type of installation: Kiosk.) [cite: 9]


Imaging

Active Scan Area 129 x 89 mm
Illumination Sources LED visible white, Infra-red (B900), Ultra-violet (UVA)
Provided Images Visible, IR, OVD image, glare-free image, UV image
Image Formats BMP, JPG, JPG2000, PNG
Image Color Depth 24 bits/pixels [RGB, 8 bits/pixels (IR image)]



Reading Capability

Automatic Document Detection (ADD) YES
Reflection Removal (RR) YES
Adaptive Light Control YES
ICAO MRZ Reading ICAO compliant documents per ICAO 9303 specification Part 1, Part 1v2, Part 2, Part 3 and Part 3v2 for Type ID-1, ID-2 and ID-3 MRZ Optical Character Recognition
VIZ Reading Option Available with Adaptive Recognition VIZ OCR software
Barcode Reading 1D: UPC-A, EAN8, EAN13, Code39, Code128 and Interleaved 2 of 5 (ITF) 2D: PDF 417, Data Matrix, QR Code, Aztec Code AAMVA compliant PDF4/7 and IATA BCBP
RFID Reading Reading and writing contactless ICs according to: ISO 14443 Type A & B, BSI TR-03105; All standardized rates up to 848 Kbps



Programming & Interfaces

Supported Operating Systems Windows 7, 8, 8.1, 10+ Linux (ask for details)
Software Development Kit (SDK) Complete SDK including DLLs and demo programs
Programming Languages C/C++, C#, Visual Basic 6.0, Delphi, VB.NET, Java
General Interfaces AR native, Twain and Acuant AssureID
Status Indicators Four programmable status LEDs (blue, green, yellow, red)
Advanced Document Authentication Data consistency checks: MRZ; RFID; B900 and UV dull paper check; Bearer’s printed photo vs. RFID DIGI2
Additional Authentication Options VIZ and non-ICAO document reading; Automated verification based on document specific security features in visible white, IR and UVA
PC Connection USB 2.0 high speed (USB 3.0 compatible)
Firmware Upgrade Automatic, via USB



Mechanical and Other Data

Size with passport fixer 150 mm × 195 mm × 117 mm (5.90” × 7.67” × 4.60”)
Size without passport fixer 150 mm × 195 mm × 108 mm (5.90” × 7.67” × 4.25”)
Weight 1.01 kg (2.15 lbs)
Operating Temperature 5 °C to 45 °C (45 °F to 113 °F)
Operating Humidity 0-90 % (non-condensing)
Power supply (V DC) 12 V DC
Case Housing Sturdy ABS-PC plastic
Maintenance No moving parts, maintenance-free operation
Warranty 3-year warranty, upgradeable
